Features & Advantages of Our product:

1.Black and bright—an elegant contradiction

2.Experience the new visual standard in indoor LED displays: true black at 2,000 NIT brightness, with a contrast ratio of 4,000:1.

3.Black silicon resin (instead of traditional white epoxy) produces a sheer black surface.

4.Replaceable “light trap shaders eliminate ambient reflection.

5.Ultra black exterior casting blends components into a single, uniform color.

Technical Data:

Pixel Configuration

1R,1G,1B

Virtual/Visual pixel pitch(mm)

8

Physical/Real pixel pitch(mm)

16

Pixel density(dots/sqm(Virtual/Visual)

15625

Pixel density(dots/sqm(physical/real)

3906

Calibrated Brightness

7500 nits(adjustable)

Color temperature

3,500° ???9,500° K(adjustable)

Contrast ratio

4,000:1

Brightness Adjustment

100 grade auto-adjustment

View angle(degree)(50% brightness)

Horizontal: 120° (80° off center); Vertical: 70° (+25°/-45° off center)

Color Capability

4.4 trillion

Refresh rate(Hz)

>2400 Hz

Frame frequency(Hz)

>60 Hz

Interface port

DVI interface(DVI connector)

Input signal

Video: PAL/NTSC  Optioned: VGA, video, DVD,TV

Protection grade

IP65 front side/IP54 backside

Operating temperature(Celsius degree)

-20C-55'

Storage temperature(Celsius degree)

-30???55'

Operation Humidity(RH)

0-95%

Storage Humidity(RH)

0-99%

Lifetime(hours)(50% brightness)

100,000 hOurs

Servicing

Front and Back

Power supply

100-240V/50-60HZ

Screen Operation mode:  static

1

LED Drive

constant-current drive

Power consumption(W/???:Maximum

1094

Power consumption(W/???:Average

438

Solutions & Product introduction about our LED display:

Chief Electronic Information Display Screen

Increase government transparency and effective public and a government with credibility, and improve government image.
