APOLLOMI digital led screen

Features & Advantages of Our product:

1.Attractive price, reliable quality & wide application: commercial & advertising LED display, Sports stadium LED displays, mobile truck & trailer LED displays, digital LED billboards, rental LED display, entertainment venues LED displays, train & bus station, air port, telecommunication etc. transportation LED displays.2.Deep blacks, bright whites, wide viewing angles, high brightness & 4,000 to 1 contrast ratio ???resulting in razor-sharp, high-bright images. Fit for installation requiring close viewing and increased contrast.

3.First-class LED chip: high strictly selected LED chip to ensue the long lifetime and high brightness of our LED screen system.

4.Extended lifetime: provides up to 100,000 hours of display life with optimized display components.

5.Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience to get short ROI of your LED screen’s investment.

6.Thermally efficient housing & enhanced uniformity: pulls heat away from critical internal components by evenly distributing heat & eliminates hotspots that effect display lifetime.

7.Seamless display face: disguises breaks between individual modules with a custom louver design.

8.Low power consumption & clear vivid image quality even in direct, full-on sunlight to ensure you attract more audience to achieve short ROI of your investment.

9.Easy, quick installation & convenient servicing interface: front and rear cabinet access make the maintain work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business

10.Customized shape & size: brings nearly any creative display concept to life with a flexible, module-based design platform.

Technical Data:

Line-and-column spacing(pixel pitch:mm) 12

Physical pixel density(dots/??? 6944

Calibrated Brightness 8500 nits(adjustable)

Calibrated Brightness proportion ratio R: G: B = 30%:60%:10%

Color temperature 6,500° ???9,500° K(adjustable)

Contrast ratio 4,000:1

Brightness adjustment(dimming) 100 grade auto/manual-adjustment

Optimal view angle(degree)(50% brightness) Horizontal: 120° (60° off center); Vertical: 70° (+25°/-45° off center)

Readability viewing angle Horizontal: 120° (60° off center); Vertical: 70° (+25°/-45° off center)

Color Capability 4.4 trillion

Refresh rate(Hz) >1200 Hz

Frame frequency(Hz) >60 Hz

LED Drive  mode constant-current drive

Lifetime(hours)(50% brightness) 100,000 hours

Interface port DVI interface(DVI connector)

Input signal Video: PAL/NTSC  Optioned: VGA, video, DVD,TV

Signal transmission direction Horizontal

Operating temperature(Celsius degree) -30???65'

Operation Humidity(RH) 0-99%

Protection grade IP65 front side/IP43 backside

Servicing Front and Back

Control mode Synchronous & Asynchronous image  available

Communication Options Synchronous & Asynchronous image  available

Power 120/240 V  AC single phase/50-60HZ

Power consumption(W/???:Maximum 900

Power consumption(W/???:Average 360

Screen Operation mode:  scan/static 1/4

Pixel Data

Pixel Configuration(DIP 346 1R1G1B ) Red wave length: 625~630nm

Green wave length: 525~530nm

Blue wave length: 470~475nm

Modular Module Data

Module Configuration(Pixels quantities of the module) Length 16

Height 16

Module Dimensions(mm) Length 192

Height 192

Width 20

Modular Cabinet  Data

Cabinet Configuration(standard/modular)(module quantities of the cabinet) Length 5

Height 5

Cabinet Dimensions(standard/modular)(mm) Length 960

Height 960

Width 170

Solutions & Product introduction about our LED display:

digit led screen have to be produced without the outrageous expenses. Slogans have to be short yet catchy enough to be noticed. There are just so many billboards that a great number of billboard advertising companies are also present. Digital printing, screen printing, and electric sign companies are open for business. The industry of vinyl sign production is actually the most fluid. Plus, according to EMC Outdoor, outdoor advertising companies in the United States offered two thousand digital billboard displays for rent in 2010. A lot of mobile billboard advertising companies also offer a variety of packages for clients to choose from. Most of these packages are inclusive of all operating costs except for local taxes. The billboards have to capture the attention that they need. Nevertheless, if the billboard is in the right spot, for the right duration of time, with the right message to consumers, it will surely be effective.Single column, double column and some other forms of column structure:Post bed LED display is mainly used in highways, streets or square and some open areas, so such a display needs the brightness, structure, waterproofing and other unique requirements.

Company profile introduction:

APOLLOMI is China LED display screen manufacturer, we offer indoor LED display, outdoor LED display, creative LED display and LED screen. Our products are used in sports stadium, waiting room, exhibition building, performance center, square, billboard, commercial street. We provide onsite product installation, debugging and maintenance service for LED display, LED screen and LED board, welcome. We have provided outstanding LED panel solutions for opening ceremony of 2008 Beijing Olympics, including Olympic Ring and ground scroll display system.We have 50 RD engineers in electrical, mechanical, opto and color analysis work on lectronic circuit-board design, software, optics, heat management, structure, power distribution. We have obtained 25 technical patents. APOLLOMI products are widely used in entertainment venues, sports stadium, waiting room, exhibition building, performance center, square, commercial street. APOLLOMI ad. LED displays suit for entertainment venues, sports stadium, stage, airport, railway station, bus station, highway, bank etc. Our LED display has the advantages of good weather resistance, low power consumption and uniform illumination.

We have more than 21 years researching & manufacturing experience in this field. Our mass production mode & 30000 SQM manufacturing base guarantee our high quality, economic average cost & fast delivery ability.
