digit LED panel

Features & Advantages of Our product:

IP65 LED surface

100,000-hour lifetime

7,600 NIT brightness

3,000:1 contrast ratio

16-bit color processing

Impact-resistant shaders

120W/tile consumption

800Hz (60fps) refresh rate

10,12,16,20mm pixel pitch: 8,500 nits;4, 4.85, 5, 6, 7.2, 7.62, 10, 12.5, 16, 18.75mm pixel pitch: 1,800 nits

Technical Data:

Line-and-column spacing(pixel pitch:mm) 14.0

Physical pixel density(dots/??? 5102

Calibrated Brightness 8500 nits(adjustable)

Calibrated Brightness proportion ratio R: G: B = 30%:60%:10%

Color temperature 6,500° ???9,500° K(adjustable)

Contrast ratio 4,000:1

Brightness adjustment(dimming) 100 grade auto/manual-adjustment

Optimal view angle(degree)(50% brightness) Horizontal: 120° (60° off center); Vertical: 70° (+25°/-45° off center)

Readability viewing angle Horizontal: 150° (75° off center); Vertical: 90° (+35°/-55° off center)

Color Capability 4.4 trillion

Refresh rate(Hz) >1200 Hz

Frame frequency(Hz) >60 Hz

LED Drive  mode constant-current drive

Lifetime(hours)(50% brightness) 100,000 hours

Interface port DVI interface(DVI connector)

Input signal Video: PAL/NTSC  Optioned: VGA, video, DVD,TV

Signal transmission direction Horizontal

Operating temperature(Celsius degree) -30???65'

Operation Humidity(RH) 0-99%

Protection grade IP65 front side/IP43 backside

Servicing Front and Back

Control mode Synchronous & Asynchronous image  available

Communication Options Wire Ethernet, Fiber Ethernet,RF wireless,GPRS

Power 120/240 V  AC single phase(50-60HZ)

Power consumption(W/???:Maximum 1000

Power consumption(W/???:Average 400

Screen Operation mode:  scan/static 1/4

Pixel Data

Pixel Configuration(DIP 346 1R1G1B ) Red wave length: 625~630nm

Green wave length: 525~530nm

Blue wave length: 470~475nm

Modular Module Data

Module Configuration(Pixels quantities of the module) Length 16

Height 16

Module Dimensions(mm) Length 224

Height 224

Width 20

Modular Modular Cabinet  Data

Cabinet Configuration(standard/modular)(module quantities of the cabinet) Length 5

Height 5

Cabinet Dimensions(standard/modular)(mm) Length 1120

Height 1120

Width 170

Solutions & Product introduction about our LED display:

1. It has passed the Stringent CE standard and it has 0 electromagnetic interference, high stability and reliability.

2. It is very light and simple, for the display body is made by SMD modules, which reduce greatly the weight and thickness of the display and thereby reduce the difficulties of the assembling.

3. It supports a variety of stock data base, and keeps it updating timely and makes it a clearer control.

4. The programming is simple and practical, and is compatible with the database entry system which ensures the real-time data transmission from multi-interface and multi-channel ports.

5. Meanwhile we use the cylinders to fix on the screen body, which facilitates greatly the installation and later maintenance. s

Company profile introduction:

We are committed to providing a wide array of energy efficient, long lifespan displays, such as sport stadium LED display, advertising board, square LED screen, stage display screen, wall large display, and airport display screen. We manufacture LED displays screens using the most advanced technology and equipment. We also emphasize customer services. We adopt strict quality control system and have customer-friendly warranty policies. Our high quality products are highly recognized by customers from home and aboard. We dedicate ourselves on the R&D, production and marketing of LED display,pixel LED lamp,high power LED lamp, and the hot sold items of these series are: pixel LED light，LED video floor,outdoor LED display,indoor LED display,LED message sign,rental LED screen,LED grid screen,LED curtain screen,soft LED screen,LED flexible curtain,LED curved screen,pixel LED screen. With professional structure and electronic R&D team,therefor, APOLLOMI　LED LED products own advanced technology and competitive price in the market,which win high public praise all over the world. In LED screen series, LED video pixel,LED light string,indoor LED screen,outdoor LED screen,super thin LED screen,soft flexible LED screen,LED dancing floor are our elite items,on which we adopted many international standard patent technology. Pls click products button to view more.

We produce displays by utilizing advanced technologies and equipment. Due to high quality, all our LED displays are UL, CE, FCC and ETL certified, and are used in 2010 Shanghai Expo. Our LED display is used in 2008 Beijing Olympic and 2010 Shanghai Expo.

Our advertising LED display screen suits for sports stadium, stage, airport, railway station, bus station, highway, bank and hospital. We also design and develop video display control, lighting control and information display control system. We provide complete solutions for LED, LCD/PDP and LED lighting display system. Our LED display is of good weather resistance, low power consumption and uniform illumination.

Our Al-Alloy material cabinet is the perfect combination of lightness with firmness. LED display can sustain heavy load without video distortion. UV proof and IP65 protection rating. In addition to flat screens, curved video screens and special-format screens can be realized. Both rigging and standing installation are available. Be able to show lighting effect, figure, letter, animation and video intelligently. We have been a partner of the Beijing Olympic organizing committee to supply large LED display. Due to high quality, reliable performance and competitive prices, our displays earned considerable appraises. Our CE certified display is highly recognized by customers at home and abroad. We are competent and are your one stop shopping centre for all your display needs. Our led panel is of good weather resistance, low power consumption and uniform illumination.

Our high quality, reasonably-priced screen is popular in domestic market and foreign market. Our LED display screen is used in many airports, such as airport of Guangzhou, China.

Stunning flicker-free broadcast quality video images can be obtained as a result of our 16 bit color processing and super high refresh rate. Adjustable constant current source ensures minimum grayscale loss, resulting in optimal picture under environment of any brightness, whether daytime or nighttime. We adopt LED lamps from leading suppliers such as Nichia, Cree, so as to ensure quality of our LED screen. We can produce quality outdoor led panel, indoor LED display and creative LED display at reduced costs.
