digital signs

Features & Advantages of Our product:

Oriented the conception of light-weight, less-occupation, clear-viewing, the thickness of each cabinet is tailored down to 6.5cm, is super thin and light-weight LED video display specially designed for rental or mobile use, as both backdrop applications and advertising billboard - rental LED screen. As super thin LED screen, adopting the supper thin, light power supply and electric fan, and FLAKE products never occupy unnecessary room needed by other devices; and also never puts unnecessary weight to the mounting structures.

The super-bright SMD 3-in-1 LED pixel configuration brings true possibilities of ensuring the image and video sharp, exquisite and brilliant enough for stage events, presentation, TV studio, etc.

Key benefits:

Phenomenal black levels

4,000:1 contrast ratio

2,000 NIT brightness

16-bit color processing

Replaceable shaders

Consistent uniformity

High Definition-ready

Modular creativity

Technical Data:

Line-and-column spacing(pixel pitch:mm) 14.0

Physical pixel density(dots/? 5102

Calibrated Brightness 8500 nits(adjustable)

Calibrated Brightness proportion ratio R: G: B = 30%:60%:10%

Color temperature 6,500° ?9,500° K(adjustable)

Contrast ratio 4,000:1

Brightness adjustment(dimming) 100 grade auto/manual-adjustment

Optimal view angle(degree)(50% brightness) Horizontal: 120° (60° off center); Vertical: 70° (+25°/-45° off center)

Readability viewing angle Horizontal: 150° (75° off center); Vertical: 90° (+35°/-55° off center)

Color Capability 4.4 trillion

Refresh rate(Hz) >1200 Hz

Frame frequency(Hz) >60 Hz

LED Drive  mode constant-current drive

Lifetime(hours)(50% brightness) 100,000 hours

Interface port DVI interface(DVI connector)

Input signal Video: PAL/NTSC  Optioned: VGA, video, DVD,TV

Signal transmission direction Horizontal

Operating temperature(Celsius degree) -30?65'

Operation Humidity(RH) 0-99%

Protection grade IP65 front side/IP43 backside

Servicing Front and Back

Control mode Synchronous & Asynchronous image  available

Communication Options Wire Ethernet, Fiber Ethernet,RF wireless,GPRS

Power 120/240 V  AC single phase(50-60HZ)

Power consumption(W/?:Maximum 1000

Power consumption(W/?:Average 400

Screen Operation mode:  scan/static 1/4

Pixel Data

Pixel Configuration(DIP 346 1R1G1B ) Red wave length: 625~630nm

Green wave length: 525~530nm

Blue wave length: 470~475nm

Modular Module Data

Module Configuration(Pixels quantities of the module) Length 16

Height 16

Module Dimensions(mm) Length 224

Height 224

Width 20

Modular Modular Cabinet  Data

Cabinet Configuration(standard/modular)(module quantities of the cabinet) Length 5

Height 5

Cabinet Dimensions(standard/modular)(mm) Length 1120

Height 1120

Width 170

Solutions & Product introduction about our LED display:

Is your business missing in action along your street? Is it passed, unnoticed, by thousands of motorists each day due to an inadequate, antiquated or missing sign? Without adequate signage your business is losing money. An electronic message center costs less per month than any other major advertising media. A LED Electronic Message Center supports your media effort by reinforcing your message at the point of purchase. Your message reaches each consumer that stops or passes by your location everyday. Using an LED message centers means instantaneous advertising and quick reaction to change that can influence potential customers.w

Company profile introduction:

APOLLOMI leads the way in LED display manufacturing & technology. Its outdoor & indoor commercial advertising LED display, rental use LED display, fixed installation led panel, sports stadium perimeter LED display, mobile trailer LED display, water floating LED display, transparent LED curtain display, digital LED billboard, LED mesh display screen for skyscraper's decoration, arc led panel, LED components & complete LED full color video systems undergo stringent quality control at ISO 9001-certified manufacturing plants.

APOLLOMI strong, experienced & reliable R&D team ensure any kinds of your OEM, ODM cooperation complete in a very fast speed, high quality and strong delivery ability.

APOLLOMI fast growth needs your help, support, wisdom & strength. We are still open for local cooperation with you in your district. If you have interest to be our partner in your local district, please let us know.
