Scoreboard LED signs

Screen parameter

pixel pitch                        25mm

LED configuration                2R,1G,1B

LED Density                       1600 pixel/sqm

Hor. Viewing angle              110deg

Vert. viewing angle              45deg

Ruggedness                       IP65

Temperature                       Operating-40~85deg Storage-55~150deg

Operating Humidity:            10~99%

Storage Humidity                 10~99%

Net Weight                         70KG

Certification                        UL,CE,ROHS,CCC

Cabinet Dimension               l:1280mm h :960mm w:187mm

Gray Scale:                         4096

Driving Method                     Static

Life span                            50000H

Luminance                          6000cd/aqm

Power                                Max:750w/sqm Average :300W/sqm

LED display description And Advantages

We use full color pixel of red, green and blue as the luminous components, to reveal the beauty of the nature. LED Electron Screen is the most advanced outdoor led screen which uses the independent video control system, the fiber transmission to control signals and independent cabinets. The types of outdoor screens include P10, P12,P14,P16,P18,P20,P25,P30, with single color, dual-color, and full color. During the production, we select and use imported LED chips, excellent components, with precise and normative operation. There are some features as follows: high brightness, rich colors, long life span, easy operation and maintenance.

There are Circular LED Screen around the ground floor of the stadium which is made of 110 screens and used to broadcast video images to build warm atmosphere, such as images of fireworks and water spraying, etc. The score and time could be set up and controlled by the timing and scoring control system, and projected to the funneled LED screen and the circular one via equipments in the control room at the same time, meantime, the timing clock and match clock in the dressing room are synchronous with the system, to ensure the perfect order and equal result of matches.
