P12 outdoor LED display

Screen parameter

pixel pitch                          12mm

LED configuration                2R,1G,1B

LED Density                       5102 pixel/sqm

Hor. Viewing angle              110deg

Vert. viewing angle              45deg

Ruggedness                       IP65

Temperature                       Operating-40~85deg Storage-55~150deg

Operating Humidity:            10~99%

Storage Humidity                 10~99%

Net Weight                         70KG

Certification                        UL,CE,ROHS,CCC

Cabinet Dimension               l:1280mm h :960mm w:187mm

Gray Scale:                         4096

Driving Method                     Static

Life span                            50000H

Luminance                          6000cd/aqm

Power                                Max:750w/sqm Average :300W/sqm

LED display description

LED Display Screen is a kind of high-tech products including photoelectric technology, micro-electric technology, computer technology and information processing technology as well as display technology. According to the applications, it includes Indoor LED panel, Semi-outdoor LED panel, and Outdoor LED display; According to the primary colors, Single color LED display, Dual color LED screen, and Full color LED display; According to the functions, Strip LED Screen, Image-text LED screen, and Multimedia LED display . All the LED screen are designed in modules, and the display part connects well with the control part, with good compatibility among systems. LED display cabinets could connect with each other arbitrarily, and the installation is easy. Screens are controlled by computer, and display the contents synchronously (or asynchronously) displayed by the monitor of the computer. Screens share information with internet, can display video signals, pictures and animation, etc. LED Display Screen is widely used in railway, aviation, stadium, meeting room, highway, commercial plaza, stock market, traffic control center, and hotel, etc.
