Hoisting Advertising LED panel

Screen parameter

pixel pitch 12mm

LED configuration 2R,1G,1B

LED Density 6944pixel/sqm

Hor. Viewing angle 110deg

Vert. viewing angle 45deg

Ruggedness IP65

Temperature Operating-40~85deg Storage-55~150deg

Operating Humidity: 10~99%

Storage Humidity 10~99%

Net Weight 70KG

Certification UL,CE,ROHS,CCC

Cabinet Dimension l:1280mm h :960mm w:187mm

Gray Scale: 4096

Driving Method Static

Life span 50000H

Luminance 6000cd/aqm

Power Max:750w/sqm Average :300W/sqm

LED display description and Advantages

It’s the original genuine Circular led display in domestic, and the radius is 470mm, with 5.625°central angle, which is connected by two arcuate LED Screen. Circular LED Screen changes the arrangement of LED chips, and uses the vertical transmission mode of signals to instead of the horizontal ones. The key point is to decrease the curvature of modules and to improve the water proof function as well as the consistence of viewing angle. Unit cabinet of the screen is processed by digital tools to ensure the precision. This Circual LED sign has exported to abroad and finished the installation yet, which is highly praised by users.

1.LED panel with high brightness and consistency.

2.To adjust luminous components via exquisite image control technology，and to ensure the consistent brightness of the whole screen.

3.The grayscale of red, green and blue LED are 256 each, and there are 16,777,216 kinds of colors after revolving, that’s the genuine “fullcolor?/p>

4.High compatibility and it supports many kinds of input signals, such as S－Video、CVBS、DVI、and VGA, etc, and arc LED Display Screen could directly connect with DVD, VCD, VCR, and computers
