Outdoor Rental led displays

Screen parameter

pixel pitch 20mm

LED configuration 2R,1G,1B

LED Density 5102 pixel/sqm

Hor. Viewing angle 110deg

Vert. viewing angle 45deg

Ruggedness IP65

Temperature Operating-40~85deg Storage-55~150deg

Operating Humidity: 10~99%

Storage Humidity 10~99%

Net Weight 70KG

Certification UL,CE,ROHS,CCC

Cabinet Dimension l:1280mm h :960mm w:187mm

Gray Scale: 4096

Driving Method Static

Life span 50000H

Luminance 6000cd/aqm

Power Max:750w/sqm Average :300W/sqm

LED display description And Advantages

LED screen manufactured in our factory is adaptable in any circumstance. Besides, outdoor LED screen could provide solutions of high quality display for any athletic contests, and it is the binding of video control system, timing system and scoring system. We emphasize on solutions of LED signs in Stadiums industry and advertisement. LED panel can display advertisement constantly and effectively.

There are Circular LED Display Screen around the ground floor of the stadium which is made of 110 screens and used to broadcast video images to build warm atmosphere, such as images of fireworks and water spraying, etc. The score and time could be set up and controlled by the timing and scoring control system, and projected to the funneled screen and the circular one via equipments in the control room at the same time, meantime, the timing clock and match clock in the dressing room are synchronous with the system, to ensure the perfect order and equal result of matches.
