P5 indoor fullcolor led screen

Screen parameter

pixel pitch 5mm

LED configuration 2R,1G,1B

LED Density 40000 pixel/sqm

Hor. Viewing angle 110deg

Vert. viewing angle 45deg

Ruggedness IP65

Temperature Operating-40~85deg Storage-55~150deg

Operating Humidity: 10~99%

Storage Humidity 10~99%

Net Weight 70KG

Certification UL,CE,ROHS,CCC

Cabinet Dimension l:1280mm h :960mm w:187mm

Gray Scale: 4096

Driving Method Static

Life span 50000H

Luminance 6000cd/aqm

Power Max:750w/sqm Average :300W/sqm

LED display description

There are 15625dots per area of Indoor Fullcolor LED Screen PH8 , of which the pixel size is 8mm, with 1R1G1B LED chips imported from Japan, to achieve SMD technology. The grayscale of each is 256, and 16,777,216 kinds of colors in total. Dynamic scanning technology is used to ensure the stability of images, the precision of display effect and variety of animation; cabinets are made of aluminium alloy, so it’s much lighter. On the other hand, LED Screen can display text, pictures, animation as well as video, and the display effect is no longer restricted by the high-capacity of contents, because we own the top technology in the industry through ten-year’s research and development.
