P4 indoor adversiting full color led

parameter

pixel pitch 4mm

LED configuration 1R,1G,1B

LED Density 62500 pixel/sqm

Hor. Viewing angle 110deg

Vert. viewing angle 45deg

Ruggedness IP54

Temperature Operating-40~85deg Storage-55~150deg

Operating Humidity: 10~99%

Storage Humidity 10~99%

Net Weight 70KG

Certification UL,CE,ROHS,CCC

Cabinet Dimension l:1280mm h :960mm w:187mm

Gray Scale: 4096

Driving Method 8 scan

Life span 50000H

Luminance 1800cd/aqm

Power Max:750w/sqm Average :300W/sqm

LED display description

Dynamic Fullcolor LED panel is made of single pixel which is made of SMD 3-in-1 with 1R1G1B LED. White balance is achieved with scientific color matching. It’s metal structure which is secure and reliable, and easy to install. Screen is assembled by some unit cabinet, and controlled via computer to return images displayed to the original shape. The common indoor full-color LED panel is made of selected LED chips from famous factories and full automatic equipments with plastic Curvers, what’s more, the production and quality test are both under the circumstance of high temperature to ensure the clearance of color.
