P16 outdoor roof led display

Screen parameter
pixel pitch                          16mm
LED configuration                2R,1G,1B
LED Density                       3906 pixel/sqm
Hor. Viewing angle              110deg
Vert. viewing angle              45deg
Ruggedness                       IP65
Temperature                       Operating-40~85deg Storage-55~150deg
Operating Humidity:            10~99%
Storage Humidity                 10~99%
Net Weight                         70KG
Certification                        UL,CE,ROHS,CCC
Cabinet Dimension               l:1280mm h :960mm w:187mm
Gray Scale:                         4096
Driving Method                     Static
Life span                            50000H
Luminance                          6000cd/aqm
Power                                Max:750w/sqm Average :300W/sqm

LED display description

It’s the most popular type used when the screen size is not so large or high precision is required (LED Outdoor Fullcolor Display Screen P16). The technologies used to control P16 include real image, virtual, virtual with dot by dot correction technology, while, the virtual technology is most popular which is mature. We adopt this technology in general projects. Virtual with dot by dot correction technology is original from abroad and used widely in domestic from year 2008. It’s welcomed by high-end customers, however, the cost is high. LED Display Screen P16 is high level, so we suggest customers choose virtual technology to save the cost if the screen size is more than 40sqm.
